Manufacturers of :- High Precision Chemical Process Pump, Plunger Type Metering Pump, Diaphragm Type Metering Pump, Dosing Pumps, Gear Pump, Vacuum Pump & All Kinds of Valves.


Specialist In
* Plunger Type Metering Pumps
* Diaphragm Type Metering Pumps
* Steam Jacketed Plunger Pumps
* Metering Dosing Pumps
* Toothpaste Pump



Plunger Type Metering Dosing Pump, Diaphragm Type Metering Pump, Steam Jacketed Metering Pump, Mumbai, India  Products
Plunger Type Metering Dosing Pump

Plunger Type Metering Dosing Pump Plunger Type Metering Dosing Pump

JAKIM PUMPS Manufacturers of Plunger Type Metering Dosing Pump for norhazardous liquids, Because of their simple dosing they are quite economical. They can be provided with flushing connections.

The company also manufactures Hydraulically operated Single and Double Diaphragm type and Remote head type for Hot liquids and Jacketed Type for Molten Liquids. The range includes high precision positive displacement pump conforming to API 675. Typical application for our pumps are useful accurate dosing and Mixing of acids, alcoholic, slurries, Viscous liquids etc. They are used in Chemical Plant, Fertilizer plant, Water Treatment Plant, Shop Plant, paper Industries, Pharmaceutical Industries, Thermal Power projects, and Plastic Industries.

Our range covers everything from the single pump to completed automated meter in dosing system and comprises of plunger and diaphragm pump with metering range from various capacity and pressure from Two to Fifteen thousand LPH. Pump can be offered in Simplex, Duplex, Triplex, and Multiple Heads handling for different chemical with a common Motor. Each heads would have independent connection and capacity of each heads can be also independently adjustable.

The pump discharge is variable while pump is running or at rest from Zero (0%) to full stork (100%) by means of a precision Machined Crank equipped with a stork length adjustment mechanism. The stork of the pump controlled either Manually (Local) or Automatic electrically (Remote) 4 to 20 MA.

Wetted parts can be offered in S.S.316 or 304, Carbon Steel, PVC, PP, Teflon, PVDF, Alloy 20, Hastally B or C, Titanium etc.
Diaphragm Type Metering Pump

Diaphragm Type Metering Pump Diaphragm Type Metering Pump

JAKIM PUMPS Manufacturers of Hydraulically Operated Single Diaphragm Type and Double Diaphragm type metering pump for suitable service conditions involving haradoustoxic, radio active or poisonous liquid where product leakage is not at all permitted. The Diaphragm is hydraulically actuated and has a long life as it is always in hydraulic balance, with the liquids being pumped on one side and actuating fluid on the opposite side. Its function is basically that of a partition. The diaphragm material is usually Teflon. The system is safety guarded by a in built Relief Vacuum Valve on the hydraulic side. For very severe duty conditions or when handling slurry or hot liquids, double diaphragm and remote heads can be provided.


Steam Jacketed Metering Pump

Steam Jacketed Metering Pump Steam Jacketed Metering Pump

JAKIM PUMPS Manufacturers of steam jacketed metering pump for molten liquids. The jacketed encloses the Check Valves and Gland Chamber. The valves are cartridge type and can be removed for servicing without dismantling the suction and discharge connections.
