K.B.MACHINERIES Company, a company committed and dedicated to Winding Machines Industry.

In early 1960, we started with Hand Operated (Manual) winding machines, Subsequently we developed Automatic

Bobbin / Transformers winding machines of Single & Multiple coils.

We have put up constant efforts to carryout Research & Development for upgrading above Winding Machines.

Large-Medium & Small Scale Industries are our valuable clients and they are fully satisfied with Quality and Technology.

We have well equipped in house capacity, experience of Three Decades and Know-how to meet Custom Made requirements of Winding Machines and can offer machines from various models of manual simple model to Programmable models.

  Products :

Manual Motor Coil Winding Machines
Manual Motor Coil Winding Machine, With Step Arbor, With Straight Arbor, With Motor, Mumbai, India Very ideal machine for repair shop and technical institute.
It can wind both single and three phase motor coils. With straight and step coils.
Useful for winding motors from 1/8 hp to 40 hp using five arbors.
-----------------------------------------------------------------------------------------------------------------------------------------

Light Duty Motor COIL Winding Machine
Light Duty Motor Coil Winding Machine, Heavy Duty Tensioner For Motor Winding Machine, Winding Coils From 2 HP to 100 HP, Mumbai, India
Face Plate Diameter
:
300mm
Center Height
:
900mm approx
Motor
:
1HP 3phase with electromagnetic DC. Brake with rectifier
Winding Speed
:
60 to 100rpm
Counter
:
5 Digit Mechanical Counter. (Electronic Counter Optional)
Extension Shaft
:
250mm
Reel Carrier
:
(optional)
Inching Operation By Foot Switch (Additional Accessories On Request At Extra Cost.)
MODIFICATION CAN BE MADE ON CUSTAMER REQUIREMENT.
Arbors and Fixtures of different types available prices on request.
-----------------------------------------------------------------------------------------------------------------------------------------

Manual Transformer Winding Machine
MANUAL TRANSFORMER WINDING MACHINE
HWM 1
Specification
Wire Range
:
18 to 46 swg.
Max. Dia. of Coil
:
200mm
Center Height
:
100mm
Center Distance
:
120mm
Counter
:
Mechanical
Single Reel Carrier
-----------------------------------------------------------------------------------------------------------------------------------------

CNC Winding Machine
CNC Linear Winding Machine 5501-W
CNC Linear Winding Machine 5501-W
Wire Diameter(mm) 0.06 to 1.50 0.06 to 2.50
Winding Width(mm) 100 100
Bobbin Diameter(mm) 150 125
Speed 5000/3000 RPM 1200 RPM
Motor 0.25 HP DC 0.25 HP DC
